Name: Anchor chemical hypoxide resin of EPO PLUS RE G&B
Brand: G&amp;B Fissaggi Srl

Anchor chemical hypoxide resin of EPO PLUS RE G&B

Assortment

Technical characteristics

Anchor chemical hypoxide resin of EPO PLUS RE G&B

Anchor chemical hypoxide resin of EPO PLUS RE G&B креслення

Anchor chemical hypoxide resin of EPO PLUS RE G&B Dinmark

Chemical anchor EPO PLUS RE is a pure 3: 1 epoxy resin for structural applications. Option 1 is CE certified for use on cracked or uncracked concrete with threaded strips and reinforcement, as well as for application on wet concrete or immersed in water. Certified on fastenings in seismic zones, categories C1 and C2.

Advantages of the G&B chemical anchor

- The fire resistance of the mount is F120. Certified for use on core holes. The chemical anchor guarantees safe fastening and high load values even on semi-rigid and perforated supports.
- If the mount is used close to the edges, it does not create tension in the support.
- Creates a waterproof connection.
- High resistance to chemicals.
- Weak exhalations.
- Good machinability even at high temperatures.

Operating temperature I:- 40 ° C ÷ + 40 ° C (short time maximum temperature + 40 ° C; long time temperature + 24 ° C).

Operating temperature II:- 40 ° C ÷ + 60 ° C (short time maximum temperature + 60 ° C; long time temperature + 43 ° C).
Storage temperature from +5 to +35 ° C.
Shelf life from the date of manufacture: 24 months.

Base material For structural applications of restructuring and sealing, for fixing on concrete with steel reinforcement, fixing in holes immersed in water and holes with a core. For complex fastening on the main building materials: stone, concrete, solid, semi-solid, hollow brick, wood.

Scope Suitable for use with bars with improved adhesion and threaded bars, for structural joints, for sealing wooden floors. Used for facades, roofs, wooden and metal structures, metal profiles, columns, beams, consoles, sanitary systems, pipes, reinforcement and sealing structures.

Material hypoxide resin.

Anchor chemical hypoxide resin of EPO PLUS RE G&B pdf

Download PDF

G&B Fissaggi Srl

Download the drawing PDF

Warning

Delivery

Payment.

Warranty

Minimum order amount 1200 UAH

Pickup from branches New mail

Pickup from post offices New mail

Targeted delivery by courier New mail

Pickup from our office in Lviv

Cashless for legal entities and individuals According to the invoice or the terms of the individual agreement

Відеоінструкція:

«Як здійснити оплату через Privat 24»

Exchange or refund within 14 days

Specifications
Brand	G&B Fissaggi Srl
Material	Epoxy resin
Base material	Wood
Field of application	Construction
Chemical resistance	High
Fire resistance	F120
ETA certificate	СЕ1
Volume (ml)	385585
Mounting temperature	- 40 ° C ÷ + 60 ° C
