Semi-countersunk head screw with straight slot DIN 964

Buy DIN 964

Correspondence table DIN 964

Overview

Specifications

Fastening groupStainless steel fasteners
StandardDIN 964
MaterialStainless steel A2
Diameter, mm2, 2.5, 3, 3.5, 4, 5, 6, 8, 10
Length, mm3, 4, 5, 6, 8, 10, 12, 14, 16, 18, 20, 22, 25, 28, 30, 35, 40, 45, 50, 55, 60, 65, 70, 75, 80, 90, 95, 100
HeadSemicircular
Packaging, pcs. 50, 100, 200, 500, 1000
Type of carvingFull
SlotDirect (PL)
Thread typeMetric
Threading step, mm0.4, 0.45, 0.5, 0.6, 0.7, 0.8, 1, 1.25, 1.5
AnalogISO 2010, ГОСТ 17474-80
Strength class4.8
CoatingZinc

 As a rule, to connect several parts of a structure, fasteners with countersunk heads are used on the outside. DIN 964 is a semi-countersunk head screw with a straight slot. Due to their technical characteristics and design features, DIN 964 screws create a reliable, durable connection of parts and also preserve the aesthetic appearance of the structure.

DIN 964 strength class


     DIN 964 is made of steel of strength class 4.8.

DIN 964 fastening group


     DIN 964 screws are most often made of stainless steel and belong to the stainless steel fastener group.

Materials for the manufacture of DIN 964 screws


     DIN 964 screws are made of the following materials:

  • Steel, which can optionally be coated with zinc. Zinc (Plated) protects against corrosion if the fastener is to be used in aggressive environments.
  • Stainless steel grades A2 and A4. Allows the use of fasteners at significant temperature changes and in aggressive and humid environments.


Application range of DIN 964 bolts


     DIN 964 screws are universal fasteners that can be used in various manufacturing industries; they are used in mechanical engineering, machine tool building, instrumentation and more. Its aesthetically pleasing head makes it suitable for use in furniture production, construction and finishing work. The durable and inexpensive fastener ensures a secure connection of various structures.
