DIN 6926 A2 Self-locking nut with flange

Assortment

Technical characteristics

DIN 6926 A2 Self-locking nut with flange
DIN 6926 A2 Self-locking nut with flange креслення
play img

Nut with flange is a fastener that creates a detachable threaded connection with an increased clamping area, which allows you to simultaneously redistribute the pressure on the material, and create a larger friction spot to prevent unscrewing and use nuts when fixing parts on the grooves along which this part can move . DIN 6926 has a polyamide ring in its design, which makes it self-locking.

Scope DIN 6926 is used in industrial construction, machine tool and instrument making, etc.

Material Stainless Steel. The grade of steel A2 allows to use fastenings at considerable differences of temperature and in the aggressive and humid environment.

Without coverage.

Analog EN 1663

DIN 6926 A2 Self-locking nut with flange
DIN 6926 A2 Self-locking nut with flange креслення
play img
DIN 6926 A2 Self-locking nut with flange pdf Download the drawing PDF

delivary WARNING

delivary delivary Delivery

delivary delivary Payment

delivary delivary Guarantee

Register and get a discount on all products 2%
Minimum order amount 1200 Hrn
nova-poshta
Self-pickup from department Nova Post
nova-poshta
Self-pickup from post machines Nova Post
nova-poshta
Address delivery by courier Nova Post
mist
Self-pickup from our office in Lviv
Cashless for legal entities and individuals According to the account or the terms of the individual contract
Exchange or return within 14 days

Specifications

Fastening groupStainless steel fasteners
StandardDIN 6926ISO 8100ISO 8102ART 88913
MaterialStainless steel A2
Diameter, mm45681012
Height, mm4.75.77.69.611.6
Packaging, pcs.100500
Type of carvingFull
Thread typeMetric
Threading step, mm0.70.811.251.51.75
Turnkey size, mm7810131518
TypeFlanged
